Mitofilin Polyclonal Antibody

$Human HepG2 cells fixed with 3.7% Formaldehyde in medium, blocking performed with 10% NGS in 1x PBS buffer + 0.1% Tween20. Incubated with Anti-Mitofilin\/IMMT Polyclonal Antibody (bs-1824R) at a 1:10 dilution for 1hr at RT, followed by Anti-Rabbit secondary, Cy3 conjugate at a 1:300 dilution incubated at RT for 1hr. This image was kindly provided by an end-user.$

Human HepG2 cells fixed with 3.7% Formaldehyde in medium, blocking performed with 10% NGS in 1x PBS buffer + 0.1% Tween20. Incubated with Anti-Mitofilin\/IMMT Polyclonal Antibody (bs-1824R) at a 1:10 dilution for 1hr at RT, followed by Anti-Rabbit secondary, Cy3 conjugate at a 1:300 dilution incubated at RT for 1hr. This image was kindly provided by an end-user.

$Paraformaldehyde-fixed, paraffin embedded Rat brain; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with Mitofilin\/IMMT Polyclonal Antibody, Unconjugated (bs-1824R) at 1:400 overnight at 4\u00b0C, DAB staining.$

Paraformaldehyde-fixed, paraffin embedded Rat brain; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with Mitofilin\/IMMT Polyclonal Antibody, Unconjugated (bs-1824R) at 1:400 overnight at 4\u00b0C, DAB staining.

$Paraformaldehyde-fixed, paraffin embedded Mouse brain; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with Mitofilin\/IMMT Polyclonal Antibody, Unconjugated (bs-1824R) at 1:400 overnight at 4\u00b0C, DAB staining.$

Paraformaldehyde-fixed, paraffin embedded Mouse brain; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with Mitofilin\/IMMT Polyclonal Antibody, Unconjugated (bs-1824R) at 1:400 overnight at 4\u00b0C, DAB staining.

$Paraformaldehyde-fixed, paraffin embedded (mouse kidney); Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Incubation with (Mitofilin\/IMMT) Polyclonal Antibody, Unconjugated (bs-1824R) at 1:200 overnight at 4\u00b0C, followed by operating according to SP Kit(Rabbit) (sp-0023) instructionsand DAB staining.$

Paraformaldehyde-fixed, paraffin embedded (mouse kidney); Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Incubation with (Mitofilin\/IMMT) Polyclonal Antibody, Unconjugated (bs-1824R) at 1:200 overnight at 4\u00b0C, followed by operating according to SP Kit(Rabbit) (sp-0023) instructionsand DAB staining.

Applications

WB
ELISA
IHC-P
IHC-F
IF(IHC-P)
IF(IHC-F)
IF(ICC)

Reactivity

Human
Mouse
Rat

Predicted Reactivity

Overview
Catalog #	bs-1824R
Product Name	Mitofilin Polyclonal Antibody
Applications	WB ELISA IHC-P IHC-F IF(IHC-P) IF(IHC-F) IF(ICC)
Reactivity	Human, Mouse, Rat
Predicted Reactivity	Dog, Cow
Specifications
Conjugation	Unconjugated
Host	Rabbit
Source	KLH conjugated synthetic peptide derived from human Mitofilin
Immunogen Range	241-340/758
Clonality	Polyclonal
Isotype	IgG
Concentration	1ug/ul
Purification	Purified by Protein A.
Storage Buffer	0.01M TBS(pH7.4) with 1% BSA, 0.02% Proclin300 and 50% Glycerol.
Storage Condition	Shipped at 4℃. Store at -20℃ for one year. Avoid repeated freeze/thaw cycles.
Target
Gene ID	10989
Swiss Prot	Q16891
Subcellular location	Cytoplasm, Cell membrane
Synonyms	HMP; P87; P89; PIG4; Mic60; PIG52; MINOS2; P87/89; MICOS complex subunit MIC60; Cell proliferation-inducing gene 4/52 protein; Mitochondrial inner membrane protein; Mitofilin; IMMT
Background	Component of the MICOS complex, a large protein complex of the mitochondrial inner membrane that plays crucial roles in the maintenance of crista junctions, inner membrane architecture, and formation of contact sites to the outer membrane. Plays an important role in the maintenance of the MICOS complex stability and the mitochondrial cristae morphology (PubMed:22114354, PubMed:25781180).
Application Dilution
WB	1:300-5000
ELISA	1:500-1000
IHC-P	1:200-400
IHC-F	1:100-500
IF(IHC-P)	1:50-200
IF(IHC-F)	1:50-200
IF(ICC)	1:50-200
