Hsp20 (7C5) Monoclonal Antibody

Flow cytometric analysis of HeLa cells with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:50 dilution (red) compared with an unlabeled control (cells without incubation with primary antibody; black).

$Lane 1: Human skeletal muscle; Lane 2: Mouse skeletal muscle; Probed with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:1000 overnight at 4\u00b0C followed by a conjugated secondary antibody for 60 minutes at 37\u00b0C.$

Lane 1: Human skeletal muscle; Lane 2: Mouse skeletal muscle; Probed with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:1000 overnight at 4\u00b0C followed by a conjugated secondary antibody for 60 minutes at 37\u00b0C.

$Paraformaldehyde-fixed and paraffin-embedded Mouse skeletal muscle tissue incubated with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:300, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.$

Paraformaldehyde-fixed and paraffin-embedded Mouse skeletal muscle tissue incubated with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:300, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.

$Paraformaldehyde-fixed and paraffin-embedded Mouse heart tissue incubated with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:300, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.$

Paraformaldehyde-fixed and paraffin-embedded Mouse heart tissue incubated with Hsp20 (7C5) Monoclonal Antibody (bsm-52694R) at 1:300, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.

Applications

WB
FCM
IHC-P
IF(ICC)
IHC

Reactivity

Human
Mouse
Rat

Overview
Catalog #	bsm-52694R
Product Name	Hsp20 (7C5) Monoclonal Antibody
Applications	WB, FCM, IHC-P, IF(ICC), IHC
Reactivity	Human, Mouse, Rat
Specifications
Conjugation	Unconjugated
Host	Rabbit
Source	Recombinant human Hsp20 between 50-150 amino acids
Clonality	Monoclonal
Clone #	7C5
Isotype	IgG
Concentration	1ug/ul
Purification	Purified by Protein A.
Storage Buffer	Aqueous buffered solution containing 1xTBS (pH7.4), 1%BSA, 40%Glycerol and 0.05% Sodium Azide.
Storage Condition	Store at -20°C for 12 months.
Target
Gene ID	126393
Swiss Prot	O14558
Synonyms	Heat shock protein beta-6, Heat shock 20 kDa-like protein p20, HspB6_ HSPB6
Background	Small heat shock protein which functions as a molecular chaperone probably maintaining denatured proteins in a folding-competent state. Seems to have versatile functions in various biological processes. Plays a role in regulating muscle function such as smooth muscle vasorelaxation and cardiac myocyte contractility. May regulate myocardial angiogenesis implicating KDR. Overexpression mediates cardioprotection and angiogenesis after induced damage. Stabilizes monomeric YWHAZ thereby supporting YWHAZ chaperone-like activity.
Application Dilution
WB	1:300-5000
FCM	1:20-100
IHC-P	1:200-400
IF(ICC)	1:50-200
IHC
