PDK1 (2F9) Monoclonal Antibody

$Lane 1: Rat Heart; Probed with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:1000 overnight at 4\u00b0C followed by a conjugated secondary antibody for 60 minutes at 37\u00b0C.$

Lane 1: Rat Heart; Probed with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:1000 overnight at 4\u00b0C followed by a conjugated secondary antibody for 60 minutes at 37\u00b0C.

$IF(ICC) staining with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100 in Hela cells (green). The nuclear counterstain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilized with 0.25% Triton X100\/PBS.$

IF(ICC) staining with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100 in Hela cells (green). The nuclear counterstain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilized with 0.25% Triton X100\/PBS.

$IF(ICC) staining with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100 in NIH-3T3 cells (green). The nuclear counterstain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilized with 0.25% Triton X100\/PBS.$

IF(ICC) staining with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100 in NIH-3T3 cells (green). The nuclear counterstain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilized with 0.25% Triton X100\/PBS.

$Paraformaldehyde-fixed and paraffin-embedded Human Kidney tissue incubated with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.$

Paraformaldehyde-fixed and paraffin-embedded Human Kidney tissue incubated with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.

$Paraformaldehyde-fixed and paraffin-embedded Mouse Heart tissue incubated with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.$

Paraformaldehyde-fixed and paraffin-embedded Mouse Heart tissue incubated with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100, overnight at 4\u00b0C, followed by a conjugated secondary antibody and DAB staining. Counterstained with hematoxylin.

Flow cytometric analysis of NIH-3T3 cells with PDK1 (2F9) Monoclonal Antibody (bsm-54037R) at 1:100 dilution (red) compared with an unlabeled control (cells without incubation with primary antibody; black).

$Paraformaldehyde-fixed, paraffin embedded Human kidney; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with PDK1 (2F9) Monoclonal Antibody, Unconjugated (bsm-54037R) at 1:200 overnight at 4\u00b0C, DAB staining.$

Paraformaldehyde-fixed, paraffin embedded Human kidney; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with PDK1 (2F9) Monoclonal Antibody, Unconjugated (bsm-54037R) at 1:200 overnight at 4\u00b0C, DAB staining.

$Paraformaldehyde-fixed, paraffin embedded Human heart; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with PDK1 (2F9) Monoclonal Antibody, Unconjugated (bsm-54037R) at 1:200 overnight at 4\u00b0C, DAB staining.$

Paraformaldehyde-fixed, paraffin embedded Human heart; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15min; Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes; Blocking buffer (normal goat serum) at 37\u00b0C for 30min; Antibody incubation with PDK1 (2F9) Monoclonal Antibody, Unconjugated (bsm-54037R) at 1:200 overnight at 4\u00b0C, DAB staining.

Applications

WB
FCM
IHC-P
IF(IHC-P)
IF(ICC)

Reactivity

Human
Mouse
Rat

Overview
Catalog #	bsm-54037R
Product Name	PDK1 (2F9) Monoclonal Antibody
Applications	WB, FCM, IHC-P, IF(IHC-P), IF(ICC)
Reactivity	Human, Mouse, Rat
Specifications
Conjugation	Unconjugated
Host	Rabbit
Source	Full length protein
Clonality	Monoclonal
Clone #	2F9
Isotype	IgG
Concentration	1ug/ul
Purification	Purified by Protein A.
Storage Buffer	Aqueous buffered solution containing 1xTBS (pH7.4), 1%BSA, 40%Glycerol and 0.05% Sodium Azide.
Storage Condition	Shipped at 4°C. Store at -20°C for one year. Avoid repeated freeze/thaw cycles.
Target
Gene ID	5163
Swiss Prot	Q15118
Subcellular location	Nucleus, Mitochondrion
Synonyms	[Pyruvate dehydrogenase (acetyl-transferring)] kinase isozyme 1, mitochondrial, Pyruvate dehydrogenase kinase isoform 1, PDH kinase 1, PDK1, PDHK1
Background	Mitochondrial pyruvate dehydrogenase (PDH) catalyzes the oxidative decarboxylation of pyruvate and plays a central role in the regulation of homeostasis of carbohydrate fuels in mammals. PDH activity is controlled by a phosphorylation/dephosphorylation cycle, phosphorylation leading to inactivation and dephosphorylation leading to reactivation of PDH. The phosphorylation of PDH is catalyzed by pyruvate dehydrogenase kinase (PDK), the activity of which is stimulated by the products of PDH catalysis. PDK1 consists of alpha and beta subunits; the kinase activity resides in the alpha subunit. Three PDK isoenzymes have been identified in humans (PDK1, 2 and 3) and two have been identified in rodent (PDK1 and 2).
Application Dilution
WB	1:300-5000
FCM	1:20-100
IHC-P	1:200-400
IF(IHC-P)	1:50-200
IF(ICC)	1:50-200
