TOMM22 Recombinant Antibody

25 ug total protein per lane of various lysates (see on figure) probed with TOMM22 monoclonal antibody, unconjugated (bsm-62109R) at 1:1000 dilution and 4\u00b0C overnight incubation. Followed by conjugated secondary antibody incubation at r.t. for 60 min.
25 ug total protein per lane of various lysates (see on figure) probed with TOMM22 monoclonal antibody, unconjugated (bsm-62109R) at 1:1000 dilution and 4\u00b0C overnight incubation. Followed by conjugated secondary antibody incubation at r.t. for 60 min.
The HepG2 (H) cells were fixed with 4% PFA (10 min at r.t.) and then permeabilized with 90% ice-cold methanol for 20 min at -20\u2103,the cells then were incubated in 5%BSA to block non-specific protein-protein interactions (30 min at r.t.), followed by secondary antibody incubation for 40 min at room temperature. Primary Antibody (green):Rabbit Anti-TOMM22 antibody (bsm-62109R,1:100); Isotype Control (orange): Rabbit IgG (bs-0295P). Blank control (black): PBS. Acquisition of 20,000 events was performed.
The HepG2 (H) cells were fixed with 4% PFA (10 min at r.t.) and then permeabilized with 90% ice-cold methanol for 20 min at -20\u2103,the cells then were incubated in 5%BSA to block non-specific protein-protein interactions (30 min at r.t.), followed by secondary antibody incubation for 40 min at room temperature. Primary Antibody (green):Rabbit Anti-TOMM22 antibody (bsm-62109R,1:100); Isotype Control (orange): Rabbit IgG (bs-0295P). Blank control (black): PBS. Acquisition of 20,000 events was performed.
4% Paraformaldehyde-fixed HepG2 (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min, DAPI (blue, C02-04002) was used to stain the cell nuclei. PBS instead of the primary antibody was used as the blank control.
4% Paraformaldehyde-fixed HepG2 (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min, DAPI (blue, C02-04002) was used to stain the cell nuclei. PBS instead of the primary antibody was used as the blank control.
Paraformaldehyde-fixed, paraffin embedded Human Liver Cancer; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Liver Cancer; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Liver; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Liver; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Kidney; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Kidney; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Small Intestine; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Small Intestine; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Heart; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
Paraformaldehyde-fixed, paraffin embedded Human Heart; Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min; The section was incubated with TOMM22 Monoclonal Antibody, Unconjugated (bsm-62109R) at 1:200 overnight at 4\u00b0C, followed by conjugation to the bs-0295G-HRP and DAB (C-0010) staining.
4% Paraformaldehyde-fixed HT-29 (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min, then stained with Phalloidin\/BF555 for 30 min at room temperature; DAPI (blue, C02-04002) was used to stain the cell nuclei.
4% Paraformaldehyde-fixed HT-29 (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min, then stained with Phalloidin\/BF555 for 30 min at room temperature; DAPI (blue, C02-04002) was used to stain the cell nuclei.
4% Paraformaldehyde-fixed HeLa (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min . DAPI (blue, C02-04002) was used to stain the cell nuclei.\r\n
4% Paraformaldehyde-fixed HeLa (H) cell; Triton X-100 at r.t. for 20 min; Antibody incubation with (TOMM22) monoclonal Antibody, unconjugated (bsm-62109R) 1:100, 90 min at 37\u00b0C; followed by BF488 conjugated Goat Anti-Rabbit IgG antibody (green, bs-60295G-BF488) at 37\u00b0C for 90 min . DAPI (blue, C02-04002) was used to stain the cell nuclei.\r\n
Bioss unconjugated antibody vial

Applications

  • WB
  • FCM
  • IHC-P
  • IHC-F
  • IF(IHC-P)
  • IF(ICC)
  • IP

Reactivity

  • Human
Overview
Catalog # bsm-62109r
Product Name TOMM22 Recombinant Antibody
Applications
WB FCM IHC-P IHC-F IF(IHC-P) IF(ICC) IP
Reactivity Human
Specifications
Conjugation Unconjugated
Host Rabbit
Source KLH conjugated synthetic peptide derived from human TOM22
Clonality Recombinant
Isotype IgG
Concentration Lot dependent
Purification Purified by Protein A.
Storage Buffer 0.01M TBS (pH 7.4), 1% BSA, 0.02% Proclin 300, and 50% Glycerol
Storage Condition Shipped at 4C. Store at -20C for one year. Avoid repeated freeze/thaw cycles.
Target
Gene ID 56993
Swiss Prot Q9NS69
Subcellular location Cytoplasm
Synonyms 1C9 2; hTom 22; hTom22; MST065; MSTP 065; MSTP065; TOM 22; TOM22; TOMM 22.
Background Central receptor component of the translocase of the outer membrane of mitochondria (TOM complex) responsible for the recognition and translocation of cytosolically synthesized mitochondrial preproteins. Together with the peripheral receptor TOM20 functions as the transit peptide receptor and facilitates the movement of preproteins into the translocation pore.Required for the translocation across the mitochondrial outer membrane of cytochrome P450 monooxygenases.
Application Dilution
WB 1:500-2000
FCM FCM1:50-100
IHC-P IHC-P1:100-200
IHC-F IHC-F1:100-200
IF(IHC-P) IFIHC-P1:100-200
IF(ICC) IFICC1:50-200
IP IP1:20-50

Frequently asked questions

Which applications is TOMM22 Recombinant Antibody (bsm-62109R) validated for, and at what dilution?

bsm-62109R is validated for WB(WB) (1:500-2000); FCM(FCM) (1:50-100); IHC-P(IHC-P) (1:100-200); IHC-F(IHC-F) (1:100-200); IF(IHC-P)(IF(IHC-P)) (1:100-200); IF(ICC)(IF(ICC)) (1:50-200); IP(IP) (1:20-50). These are recommended starting dilutions; optimal dilutions should be determined by the end user.

Which species does TOMM22 Recombinant Antibody (bsm-62109R) react with?

Tested reactivity: Human.

How should bsm-62109R be stored?

Shipped at 4C. Store at -20C for one year. Avoid repeated freeze/thaw cycles. Storage buffer: 0.01M TBS (pH 7.4), 1% BSA, 0.02% Proclin 300, and 50% Glycerol

What immunogen was used to raise TOMM22 Recombinant Antibody (bsm-62109R)?

KLH conjugated synthetic peptide derived from human TOM22
